一、核心加密策略选择

数字档案馆加密需同时满足长期保存与安全访问的双重需求。推荐采用分层加密策略：

存储层加密：使用AES-256-GCM算法加密文件本体
传输层加密：TLS 1.3保障网络传输安全
密钥管理：采用国密SM4算法管理主密钥，符合国内安全标准

此策略能确保即使存储介质泄露，攻击者也无法获取文件明文。

二、完整环境部署

2.1 基础环境准备

安装必备的加密库和工具：

``` Ubuntu/Debian系统 sudo apt-get update sudo apt-get install -y python3 python3-pip openssl libssl-dev sudo pip3 install cryptography pycryptodome CentOS/RHEL系统 sudo yum install -y python3 python3-pip openssl openssl-devel sudo pip3 install cryptography pycryptodome ```

2.2 密钥管理服务部署

创建独立的密钥管理服务，避免密钥与数据同存：

``` 创建密钥管理目录结构 mkdir -p /opt/archive-encryption/{keys,config,logs} chmod 700 /opt/archive-encryption/keys 生成SM4主密钥 openssl rand -hex 32 > /opt/archive-encryption/keys/master.key chmod 400 /opt/archive-encryption/keys/master.key ```

三、文件加密实现

3.1 加密脚本编写

创建encrypt_file.py实现加密功能：

``` !/usr/bin/env python3 import os from cryptography.hazmat.primitives.ciphers import Cipher, algorithms, modes from cryptography.hazmat.primitives import padding from cryptography.hazmat.backends import default_backend import hashlib import json class ArchiveEncryptor: def __init__(self, master_key_path): with open(master_key_path, 'rb') as f: self.master_key = f.read() def generate_file_key(self, file_path): """为每个文件生成唯一密钥""" file_hash = hashlib.sha256(file_path.encode()).digest() 使用SM4算法派生文件密钥 from Crypto.Cipher import AES cipher = AES.new(self.master_key[:16], AES.MODE_ECB) return cipher.encrypt(file_hash[:16]) def encrypt_file(self, input_path, output_path): """加密单个文件""" file_key = self.generate_file_key(input_path) 生成随机IV iv = os.urandom(12) 使用AES-256-GCM加密 encryptor = Cipher( algorithms.AES(file_key), modes.GCM(iv), backend=default_backend() ).encryptor() with open(input_path, 'rb') as f_in: plaintext = f_in.read() ciphertext = encryptor.update(plaintext) + encryptor.finalize() 保存加密文件（IV + 密文 + 认证标签） with open(output_path, 'wb') as f_out: f_out.write(iv) f_out.write(ciphertext) f_out.write(encryptor.tag) 保存元数据 metadata = { 'original_path': input_path, 'encryption_time': time.time(), 'key_hash': hashlib.sha256(file_key).hexdigest() } meta_path = output_path + '.meta' with open(meta_path, 'w') as f_meta: json.dump(metadata, f_meta) return True 使用示例 if __name__ == "__main__": encryptor = ArchiveEncryptor("/opt/archive-encryption/keys/master.key") encryptor.encrypt_file("/data/archives/document.pdf", "/data/encrypted/document.pdf.enc") ```

3.2 批量加密脚本

创建batch_encrypt.py处理整个目录：

``` !/usr/bin/env python3 import os import sys from encrypt_file import ArchiveEncryptor def encrypt_directory(source_dir, target_dir, encryptor): """加密整个目录""" if not os.path.exists(target_dir): os.makedirs(target_dir) for root, dirs, files in os.walk(source_dir): 保持目录结构 rel_path = os.path.relpath(root, source_dir) target_root = os.path.join(target_dir, rel_path) if not os.path.exists(target_root): os.makedirs(target_root) for file in files: if file.endswith('.meta'): continue source_file = os.path.join(root, file) target_file = os.path.join(target_root, file + '.enc') print(f"加密: {source_file} -> {target_file}") try: encryptor.encrypt_file(source_file, target_file) 加密后删除原文件（谨慎操作） os.remove(source_file) except Exception as e: print(f"加密失败 {source_file}: {e}") if __name__ == "__main__": if len(sys.argv) != 3: print("用法: python batch_encrypt.py <源目录> <目标目录>") sys.exit(1) encryptor = ArchiveEncryptor("/opt/archive-encryption/keys/master.key") encrypt_directory(sys.argv[1], sys.argv[2], encryptor) ```

四、解密访问控制

4.1 解密服务实现

创建decrypt_service.py提供安全的解密接口：

``` !/usr/bin/env python3 from flask import Flask, request, jsonify from cryptography.hazmat.primitives.ciphers import Cipher, algorithms, modes from cryptography.hazmat.backends import default_backend import hashlib import os import json app = Flask(__name__) class ArchiveDecryptor: def __init__(self, master_key_path): with open(master_key_path, 'rb') as f: self.master_key = f.read() def decrypt_file(self, encrypted_path, meta_path): """解密文件""" with open(meta_path, 'r') as f: metadata = json.load(f) 重新计算文件密钥 file_hash = hashlib.sha256(metadata['original_path'].encode()).digest() from Crypto.Cipher import AES cipher = AES.new(self.master_key[:16], AES.MODE_ECB) file_key = cipher.encrypt(file_hash[:16]) with open(encrypted_path, 'rb') as f: iv = f.read(12) ciphertext = f.read(os.path.getsize(encrypted_path) - 28) tag = f.read(16) 解密 decryptor = Cipher( algorithms.AES(file_key), modes.GCM(iv, tag), backend=default_backend() ).decryptor() plaintext = decryptor.update(ciphertext) + decryptor.finalize() return plaintext decryptor = ArchiveDecryptor("/opt/archive-encryption/keys/master.key") @app.route('/api/decrypt', methods=['POST']) def decrypt(): """解密接口""" data = request.json file_id = data.get('file_id') user_token = data.get('token') 验证访问权限（实际项目中需实现完整的权限验证） if not validate_access(file_id, user_token): return jsonify({'error': '访问拒绝'}), 403 encrypted_path = f"/data/encrypted/{file_id}.enc" meta_path = encrypted_path + '.meta' try: plaintext = decryptor.decrypt_file(encrypted_path, meta_path) 返回临时访问URL（实际项目中应生成签名URL） return jsonify({ 'url': f'/temp/{file_id}', 'expires_in': 300 }) except Exception as e: return jsonify({'error': str(e)}), 500 def validate_access(file_id, token): """简化版权限验证""" 实际实现中需对接用户认证系统 return True if __name__ == '__main__': app.run(host='0.0.0.0', port=8080, ssl_context='adhoc') ```

4.2 访问日志记录

数字档案馆系统文件加密解决方案：从原理到实战部署指南

创建access_logger.py记录所有解密访问：

``` !/usr/bin/env python3 import logging from logging.handlers import RotatingFileHandler def setup_access_log(): """配置访问日志""" logger = logging.getLogger('archive_access') logger.setLevel(logging.INFO) handler = RotatingFileHandler( '/opt/archive-encryption/logs/access.log', maxBytes=1010241024, 10MB backupCount=5 ) formatter = logging.Formatter( '%(asctime)s - %(levelname)s - %(message)s' ) handler.setFormatter(formatter) logger.addHandler(handler) return logger 在解密接口中添加日志记录 access_logger = setup_access_log() 在decrypt函数中添加 access_logger.info(f"用户 {user_token} 访问文件 {file_id}") ```

五、安全配置要点

5.1 系统加固配置

创建security_config.sh自动加固系统：

``` !/bin/bash 限制密钥文件权限 chmod 700 /opt/archive-encryption chmod 400 /opt/archive-encryption/keys/.key 设置SELinux策略（仅适用于RHEL/CentOS） if command -v semanage &> /dev/null; then semanage fcontext -a -t etc_t "/opt/archive-encryption/keys(/.)?" restorecon -Rv /opt/archive-encryption/keys fi 配置防火墙规则 if command -v ufw &> /dev/null; then ufw allow 8080/tcp comment "Archive decrypt service" ufw --force enable fi 创建专用用户 useradd -r -s /bin/false archive_enc chown -R archive_enc:archive_enc /opt/archive-encryption ```

5.2 密钥轮换策略

创建key_rotation.py实现密钥定期轮换：

``` !/usr/bin/env python3 import os import json from datetime import datetime, timedelta def rotate_master_key(): """轮换主密钥并重新加密文件密钥""" 生成新主密钥 new_master_key = os.urandom(32) 备份旧密钥 backup_time = datetime.now().strftime("%Y%m%d_%H%M%S") os.rename("/opt/archive-encryption/keys/master.key", f"/opt/archive-encryption/keys/master.key.backup_{backup_time}") 保存新密钥 with open("/opt/archive-encryption/keys/master.key", 'wb') as f: f.write(new_master_key) 更新所有文件密钥（在实际项目中实现） print("主密钥已轮换，需要重新加密所有文件密钥") return True 设置定时任务（crontab） 0 2 1 /usr/bin/python3 /opt/archive-encryption/key_rotation.py ```

六、监控与维护

6.1 健康检查脚本

创建health_check.py监控加密服务状态：

``` !/usr/bin/env python3 import psutil import requests import json def check_encryption_service(): """检查加密服务状态""" checks = { 'disk_space': psutil.disk_usage('/').percent < 90, 'memory_usage': psutil.virtual_memory().percent < 80, 'key_files': os.path.exists('/opt/archive-encryption/keys/master.key'), 'service_running': check_service_port(8080) } if all(checks.values()): return {'status': 'healthy', 'checks': checks} else: return {'status': 'unhealthy', 'checks': checks} def check_service_port(port): """检查服务端口是否监听""" try: sock = socket.socket(socket.AF_INET, socket.SOCK_STREAM) sock.settimeout(1) result = sock.connect_ex(('localhost', port)) sock.close() return result == 0 except: return False 定时运行检查 if __name__ == "__main__": status = check_encryption_service() with open('/opt/archive-encryption/logs/health.log', 'a') as f: f.write(json.dumps(status) + '\n') ```

6.2 备份恢复流程

创建backup_restore.sh实现完整备份：

``` !/bin/bash 备份脚本 BACKUP_DIR="/backup/archive-encryption" DATE=$(date +%Y%m%d_%H%M%S) 1. 备份密钥 mkdir -p $BACKUP_DIR/$DATE/keys cp -r /opt/archive-encryption/keys/ $BACKUP_DIR/$DATE/keys/ 2. 备份配置文件 cp -r /opt/archive-encryption/config/ $BACKUP_DIR/$DATE/config/ 3. 备份元数据（不包括加密文件本身） find /data/encrypted -name ".meta" -exec tar -czf $BACKUP_DIR/$DATE/metadata.tar.gz {} + 4. 验证备份完整性 sha256sum $BACKUP_DIR/$DATE/keys/master.key > $BACKUP_DIR/$DATE/checksum.txt 恢复脚本示例 tar -xzf metadata.tar.gz -C /data/encrypted/ cp keys/master.key /opt/archive-encryption/keys/ ```
